F-i3000 Automated Chemiluminescence Immunoassay Analyzer

Innovative manufacturing facilitates precision medicine

Automatic tube type magnetic particle indirect chemiluminescence

240T/h for single instrument，up to 960T/h for Four instruments online

Intra-batch repeatability, CV≤5%

Carry-over rate, ≤0.1ppm

30 reagent positions, supporting multi-package combination

240 sample positions, high-throughput injection system

Refrigerated reagent position, loading of reagent and consumables without shutdown

Three separate sample track design, surpport STAT use

High stability and low maintainability

Product Advantages

Advantage

爆炸图手机版.svg

Precision

Accurate sample loading: Liquid level follow system, with the sample loading parameter of 10-200uL, meeting different sample requirements

Accurate temperature control: 37±0.2°C

Intra-batch repeatability: CV≤5%

Low carry-over rate : The needle tip is of conical structure, ≤0.1ppm (carry-over rate )

Fourth step cleaning: unique magnetic separation cleaning, ultra-low magnetic bead loss rate

High cup cleaning efficiency: Built-in sensor
Constant

Constant throughput: No deceleration for sample testing, throughput 240T/h, and up to 960T/h in 4 online instruments

Stability: Low fault rate and low maintenance cost
Sensitive

High sensitivity reaction system: ALP chemiluminescence reaction system, with advantages in small molecule test

High sensitivity substrate: Enhanced AMPPD chemiluminescence substrate with sensitivity up to 10-18 moL
Friendly

User-friendly software: Easy to operate with a simple interface

Unique row cup system: Unattended for up to 6 hours when fully loaded

Priority for emergency treatment: Separate emergency channel

Intuitive and convenient consumable management: One-stop design, intelligent reminder
Six Patents

Automatic chemiluminescence immunoassay analyzer: CN202110661101.3

A gripper robot arm for automatic chemiluminescence immunoassay analyzer: CN202120717767.1

Automatic loading and dispatching mechanism of RV cuvette: CN202120721367.8

Calibration mechanism of a photomultiplier: CN202121642170.1

Enclosure of automatic chemiluminescence immunoassay analyzer: CN202130195641.8

Sample rack: CN202130448989.3

Chemiluminescence Reagent Package

Reagent

Gastric	Thyroid	Tumor		Endocrine	Inflammation	Diabetes	Liver Fibrosis
PGI	TSH	AFP	CEA	FSH	PCT	C-P	PIIINP
PGII	FT3	CA125	CA15-3	PRL	IL-6	INS	LN
G-17	FT4	tPSA	fPSA	LH	SAA		HA
	TT4	CA72-4	CA19-9	P	CRP^*		CIV
	TT3	CYFRA21-1	SCC	T			CG
	TG	NSE	HE4	E2
	Anti-TPO	Ferr	CA50	β-HCG
	Anti-TG	CA242	proGRP^*	AMH
	TRAb^*	β2-MG^*	PIVKA-II^**	SHBG^*
				fE3^*
				F-hCGβ^*

Infectious Diseases	Cardiac	Hypertension	Growth Hormone	Anemia	Bone metabolism
Pre S1^**	CK-MB^*	ALD^**	IGF-I^*	VB12^*	iPTH^*
HBeAg^**	D-Dimer^*	Cor^**	hGH^*	FA^*	25-OH-Vit-D^*
HBsAg^**	cTnT^*	ACTH^**			BGP^*
HBeAb^**	hs-cTnI^*	DR^**			CT^*
HBsAb^**	MYO^*	Ang II^**
HBcAb^**	LP-PLA2^*
Anti-HCV^**	BNP^*
HIV^**	NT-proBNP^*
IGRA^**	GAD65^*
Anti-TP^**	H-FABP^*
	HCY^*

Launched in December 2022 (*) under development (**)

Product Description

Introduce

F-i3000 Automated Chemiluminescence Immunoassay Analyzer
